78
Maintenance and Care
Transporting the vehicle
• When running the machine to the
site of use, the squeegee and brush
head must be raised.
• When the machine is to be transport-
ed on another vehicle or trailer, it
must be secured against rolling
away. Lash the machine down se
-
curely.
• The vehicle is provided with attach-
ment points on the left and right-
hand side to do this: at the rear of the
frame and on the sides at the height
of the entry area.
• The attachments are bolts (Fig. 33/1)
which can be pulled out from the
sides of the frame. The bolts are
locked in their projecting position by
turning them.
• The bolts also serve for loading by a
crane.
Towing the vehicle
If it should become necessary to tow
the Hakomatic B1050, only do it on a
level floor and at a maximum towing
speed of 4 kph. The tow rope must be
attached at the front lashing points.
