3.5 Filter
3.5.1 Change and Clean Cartridge Filter
• Stop engine and pull key
• Open seat hood
• Remove filter case cover
• Loosen and remove wing screws at the corner points
• Fold up and hook jolter frame
• Remove cartridge filter by pulling to top
3.5.2 Suction Fan Flap
• Before collecting wet dirt or sweeping humid surfaces, change over the flap position (from filter passage to direct air flow position).
Change over by pulling the knob on the dashboard.
• Use switch (S12) at the control wire below the dashboard to actuate the jolter motor.
Note: Driven by a V-belt, the fan constantly runs as soon as the engine (V/D) / central motor (E) is running.
