HAKO Jonas 1200 E - Steering

Service Manual
Hako GmbH Technical Service (KUD) 23843 Bad Oldesloe Edition: 05/2014
Confidential - For internal use only!
3.6 Steering
• Open maintenance flap
• Compression spring with nut:
turn jointly until a clearance of 0.2mm
remains between the coil spaces
(feeler gauge)
Representation of the
Jonas 980!
Carrier plate changed,
no cover plate
