6.7.2 LDS Programming
In order to invoke the programming level, press the left button “▲/• “ and hold depressed until display flashes. Then release button.
Set battery type:
In the display, three digits for the
discharge profile
–
charged
value are flashing (set to
2.04 V/Z in the factory).
Press the right button “►“ to increment the charged value by 0.01 V/Z or hold depressed for
continued incrementing.
After the 2.30 V/Z value has been attained, display re-starts automatically with 1.80 V/Z.
After the desired charged value of the profile has been attained, press the left button”▲/•“
once.
04
