6.7 Low Discharge Signal Sender (LDS)
Function of the low discharge signal sender is to safely protect the battery from low discharge while making full use of existing
capacities.
Before taking the battery-powered machine into operation, set the low discharge signal sender (LDS) with combined battery
charge indication to the battery type used in the machine.
Use of two battery types is admitted.
a) maintenance-free compound battery
b) low-maintenance tray battery = setting made in the factory
6.7.1 LDS Setting Mode
In order to create the setting conditions, switch on the machine and connect the configuration input of the LDS to battery plus.
To do so, connect the plug X19 at the fuse box to the contact underneath it. Now, programming of the LDS is possible.
Note:
After setting, make sure to disconnect the plugged contact again!
