Service Manual
Hako GmbH Technical Service (KUD) 23843 Bad Oldesloe Edition: 05/2014
Confidential - For internal use only!
3.8 E-Version Travelling Drive
3.8.1 Bearing Plate
- Tighten lower nut by 60 Nm with simultaneous
swinging of the wheel
- Loosen lower nut
- Swing wheel by 90°
- Tighten lower nut by 5 Nm
- If split pin holes do not match
tighten nut until next split pin hole
