Service Manual
Hako GmbH Technical Service (KUD) 23843 Bad Oldesloe Edition: 05/2014
Confidential - For internal use only!
Air-cooled, 2-cylinder, 4-stroke petrol engine with 11.93 kW at 3,600 rpm with electrical starter
Manufacturer: Briggs & Stratton
Type: Vanguard V-Twin 16HP
Nominal speed: (cyl. broom, side brush and suction fan being on) 2,500 rpm
Upper idling speed: 2,650 ± 50 rpm
Lower idling speed: 1,550 ± 50 rpm
Capacity: 480 ccm
Output at nominal speed: 8.2 kW
Torque at 2,400 rpm: 33.1 Nm
Maintenance and repair of the drive units
according to manufacturer’s prescriptions
