Service Manual
Hako GmbH Technical Service (KUD) 23843 Bad Oldesloe Edition: 05/2014
Confidential - For internal use only!
F1 Pre-fuse for key switch 15A 15A
F2 Fuse for K1 control voltage 5A 5A
F3 Fuse for K1/K5 control voltage 10A 10A
F4 Fuse for horn / pilot lamps 10A 10A
F5 Fuse for lighting, permanent plus 15A 15A
F6 Fuse for lighting, switched plus 10A 10A
F7 Fuse for parking / rear light, left-hand 5A 5A
F8 Fuse for parking / rear light, right-hand 5A 5A
F9 Fuse for jolter motor 35A 35A
F10 Fuse for direction indicator, left-hand 5A 5A
F11 Fuse for direction indicator, right-hand 5A 5A
F12 Fuse LPG (V) / pre-glowing control voltage (D) 10A 10A
F13 Fuse LPG (V) / post-heating control voltage (D) 10A 10A
F14 Main fuse for pre-glowing (D) not assigned 30A
K1 Seat contact controller
K2 Engine release relay
K3 Starter relay
K4 Time relay for pick-up delay / filter monitoring
K5 Pulse relay for jolting
K6 Relay for lighting Optional Optional
K7 Flashing relay Optional Optional
K8 Pre-glowing relay (D) not assigned
A1 LPG switch unit (V) Optional not assigned
