Service Manual
Hako GmbH Technical Service (KUD) 23843 Bad Oldesloe Edition: 05/2014
Confidential - For internal use only!
A1 Drive controller
F1 Main fuse for drive controller 160A
F2 Fuse for start lock 15A
F3 Fuse for drive controller, switched plus 10A
F4 Fuse for LDS 5A
F5 Fuse for horn 7,5A
F6 Fuse for side brush motor, left-hand (optional) 2A
F7 Fuse for jolter activation 5A
F8 Fuse for vacuumer (optional) 30A
F10 Fuse for lighting, permanent plus 10A
F11 Fuse for lighting, switched plus 10A
F12 Fuse for parking / rear light, left-hand 5A
F13 Fuse for parking / rear light, right-hand 5A
F14 Fuse for flasher relay 10A
F15 Fuse for brake lights 7,5A
F16 Fuse for jolter pulse relay 35A
F18 Fuse for broom cylinder motor 63A
F19 Fuse for main motor 63A
H4 Warning horn 63A
K1 Main contactor for drive controller
K2 Release of main motor
K3 Relay of broom cylinder./ motor
K4 Relay for main motor
K7 Time relay for pick-up delay / filter monitoring
K8 Pulse relay for jolting
K9 Relay for working floodlight Optional
K10 Flasher relay
X19 Plug configuration LDS
