2 FOR MORE INFO REFERENCE OIM MANUAL P/N FSG–MNL–00210
FROM THE VALVE X SCREEN (DISCHARGE VALVE CONTROL SCREEN), THE OPERATOR MAY SELECT
WATER ONLY, FOAM ONLY, OR CAFS. TO SELECT WATER ONLY, SWIPE THE PSI PRESET (RIGHT-
HAND SIDE OF THE WIDGET) TO THE TARGET. TO SELECT FOAM ONLY, SWIPE THE FOAM ONLY
PRESET TO THE TARGET. TO SELECT CAFS, SWIPE THE (WET, MED, OR DRY) CAFS PRESET TO THE
TARGET.
IF THE DISCHARGE DOES NOT ACTIVATE VERIFY THE CAFS SYSTEM PRESETS (PRESET 1 FOR CAFS,
PRESET 7 FOR FOAM ONLY ON THE SMARTCAFS DISPLAY) CONFIGURATION MATCHES THE SAM
CONFIGURATION. (SAM WILL ONLY ACTIVATE MATCHING CONFIGURATIONS – WET, MED, OR DRY.)
IF THE CONFIGURATIONS DO NOT MATCH, OPERATE SAM MANUALLY TO OPEN THE VALVE USING
THE SAM CONTROL CENTER. THEN OPERATE THE CAFS SYSTEM FROM THE SMARTCAFS DISPLAY.
KEEP ALL I/O PORT COVERS IN PLACE DURING USE TO PREVENT WATER DAMAGE.
ONLY TOUCH THE SCREEN IN ONE PLACE AT A TIME. THE TOUCHSCREENS DO NOT SUPPORT
MULTI–TOUCH.
SOME WATER ONLY OPERATIONS MAY DAMAGE THE CAFS SYSTEM IF THE CLUTCH IS ENGAGED.
REFERENCE CAFS QUICKSTART GUIDE, DISENGAGING THE COMPRESSOR CLUTCH (PAGE 10 OF
FSG-MNL-00176) TO ENSURE PROPER CAFS TURN OFF WHEN SAM INCLUDES A CAFS SYSTEM.
WHILE SAM CAN REDUCE PUMP OPERATOR WORKLOAD, IT DOES NOT TAKE THE PLACE OF THE
PUMP OPERATOR. THE PUMP OPERATOR STILL NEEDS TO CALCULATE THE REQUIRED LINE PRES-
SURE TO SUPPORT THE HOSE LAY AND NOZZLE IN USE. SAM WILL MAINTAIN THE SET PRESSURE
IN AUTO MODE.
