HAMPTON BAY YJAF-037-E - Setting Base Locking Mechanism

9
ENSURING THE LOCKING MECHANISM IS IN THE OPEN POSITION
Ensure the locking mechanism on the lock panel (I) is in the OPEN position by using the wrench (BB) as shown in figure 1.
Ensure the locking mechanism on the lower base cover (G) is in the OPEN position by using the wrench (BB) as shown in figure 2.
Attach the lower base cover (G) to the side panels (H).
Close the lower base cover (G) and ensure they are fully closed.
Assembly (continued)
13
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
G
BB
OPEN
CLOSED
OPEN
CLOSED
Figure 1
Figure 2
I
H
