HAMPTON BAY YJAF-037-E - Sliding Base Lock Panels

5
SLIDING THE LOCK PANELS
Slide the perforated lock panels (I) downward between the corner connectors (L).
Slide the support tube rims (J) down the lower umbrella pole (C) and connect it to the brackets (A & B).
Assembly (continued)
9
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
