Assembly (continued)
11
ASSEMBLING THE UMBRELLA SHADE
Align the holes, hold down the tabs on the pins and insert the tube to another tube until the two pieces snap into place.
15
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
