HAMPTON BAY YJAF-037-E - Raising the Umbrella Canopy

2
RAISING THE UMBRELLA
Loosen the knob on the umbrella shade as shown in figure 1 by turning it counterclockwise until it is fully loose.
Hold the umbrella handle and push the long bent tube upward as shown in figure 2 until it stops and the umbrella is fully extended.
Fully tighten the knob on the umbrella shade clockwise as shown in figure 3 to lock the handle in place.
Shake the canopy to separate with the umbrella ribs.
Operation (continued)
20
Figure 1
Figure 2
Figure 3
