HAMPTON BAY YJAF-037-E - Securing Lower Pole to Base

3
ATTACHING THE LOWER UMBRELLA POLE TO THE BRACKETS
Attach the lower umbrella pole (C) to the upper bracket (B) and the lower bracket (A) using M8x20 combination hex bolts (AA).
Assembly (continued)
NOTE : Fully tighten the bolts using the hex wrench (BB).
7
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
