HAMPTON BAY YJAF-037-E - Umbrella Operation Guide; Attaching the Crank Handle

1
ATTACHING THE CRANK
Attach the crank (D) to the handle as shown in figure 1.
Attach the crank (D) by aligning the tap with the hole on the crank (D) until it snaps into place.
To detach the crank, any properly sized tool is required to press the tap to take the crank (D) out.
Attach the crank (D) without using the tap as shown in figure 2.
To detach the crank (D), just take the crank out.
Operation
19
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE : Both methods of attaching the crank (D) are acceptable.
Figure 1
Figure 2
D
D
