HAMPTON BAY YJAF-037-E - Rotating the Umbrella

4
OPERATING THE UMBRELLA
Rotate the locking knob 180 degrees clockwise as shown in figure 1.
Hold the umbrella handle with one hand and hold the short bent tube with the other hand to rotate the umbrella as shown in figure 2.
(The umbrella can rotate up to 360 degrees.)
When the umbrella is at the desired position, rotate the knob 180 degrees clockwise as shown in figure 3.
Rotate the umbrella shade (E) until the locking knob automatically secures as shown in figure 4.
Operation (continued)
22
OPEN
CLOSE
E
Figure 1
Figure 2
Figure 3
Figure 4
