CLOSING THE UMBRELLA
When the umbrella is closed, fully loosen the knob on the umbrella shade (E) by turning it counterclockwise as shown in figure 1.
Hold the handle and pull the long bent tube downward as shown in figure 2.
Tighten the knob on the umbrella shade (E) by turning clockwise as shown in figure 3 after closing the umbrella.
Operation (continued)
24
Figure 1
Figure 2
Figure 3
E
