OPERATION
-30-
(7) Connect the power cable of welding machine to the electrical outlet. (230VAC, 1Ph)
(8) Carefully open the valve of the gas cylinder, set the required gas flow rate.
(9) Select TIG function on the front panel.
(10) Set torch operation for 2T or 4T:
• When 2T operation is selected, pressing trigger starts gas, touch and lift arc to start.
Release trigger to stop gas and arc.
• When 4T operation is selected, press and release trigger to start gas, touch and lift
arc to start. Press and release trigger again to stop gas and arc.
(8) Carefully open the valve of the gas cylinder (9) Select TIG function using the button.
and set the required gas flow rate.
(10) Select 2T or 4T trigger as required. (11) Select welding current and down slope.
(12) Select welding current as required. The selected welding current will show on
display.Set down slope time as required. The down slope time will show on the digital
display.
