Step 7
Attach the engine to the engine mount using four
4-40 x 1-inch socket head screws, four #4 washers
and four 4-40 locknuts. The included engine mount is
drilled for the Evolution 36NT.
Note: The distance from the rear of the
mount to the front edge of the drive washer
will be 4
3
/
16
-inch (107mm). Using an
engine other than the Evolution engine
may required drilling new holes in the
mount for the engine mounting screws.
Step 8
Pass the Z-bend of the throttle pushrod into the carburetor
arm.
Step 9
Slide the pushrod into the pushrod tube. Secure the
engine mount to the firewall using four 8-32 x 1
1
/
4
-inch
socket head bolts and four #8 washers. Bend the pushrod
wire slightly so it moves freely inside the pushrod tube
and will clear the muffler.
Step 10
Use a pin drill and 5/64-inch (2mm) drill bit to enlarge the
hole in the throttle servo arm.
Section 6: Glow Engine Installation
