Step 11
Slide the pushrod connector into the hole.
Step 12
Secure the connector using a 2mm washer and C-clip.
Step 13
Remove the excess arms from the servo horn. Center the
throttle servo and attach the arm to the servo.
Step 14
Position the servo in the opening with the servo arm
facing the rear of the necelle. Mark the locations for the
servo mounting screws using a felt-tipped pen.
Step 15
Use a drill and 1/16-inch (1.5mm) drill bit to drill the
locations for the servo mounting screws.
Section 6: Glow Engine Installation
