9
DESCRIPTION
Tag Description
Battery Indicator and Charging Status
Warning Indicator
Timer Indicator
Wavelength Indicator
Tags used to indicate the selected wavelength or timer
Vial type indicator for the selected method*
Lamp Status
Indicates the Active Menu
Indicates Navigation Level in Menus
Indicates Arrow Key is Active
Calibration Indicator
Auto Logging Enabled
PC Connection Established
Flash Drive Connection Established
LCD DESCRIPTION
*Note: For factory methods the indicated vial must be used to obtain valid measurements.
