Hansa C3e - Operation and Chip Collection; Attaching the Chip Catcher Bag

Hansa C3e O&M Manual - OM-004 Revision H 09/07/2019
© Hansa Chippers 2019
8
Attach the (optional) chip catcher bag
Hook the lower bar of the chip catcher bag into the
slot underneath the outlet chute.
Slide the top bar of the chip catcher bag up and over
the hooks on the top of the outlet chute.
This is how it should look when properly attached. To
remove the chip catcher bag, repeat steps 7 and 8 in
reverse order.
Operation
The chipper is self-feeding and has a large inlet opening. It can process:
• Prunings, stalks, vines, leaves, roots and vegetable matter, paper and cardboard
• Freshly cut material is better to process than dry material
• Maximum capacity is 40 mm diameter branches
It is helpful (but not required) to keep a wooden stick handy, approx. 50 mm diameter x 600 mm long for:
• Pushing in short, brushy and very leafy materials
• Keeping the inlet chute clear
7
8
9
