Hansa C3e - Bolt Torque and Technical Specifications; Recommended Bolt Tightening Torques; Hansa C3 e Chipper Specifications

Hansa C3e O&M Manual - OM-004 Revision H 09/07/2019
© Hansa Chippers 2019
18
Bolt torque
Relative Strength Bolt Marking
4.6
8.8
Recommended Tightening Torque
Recommended Tightening Torque
Bolt size
Spanner size
lb ft
Nm
lb ft
Nm
M8
13 mm
6
8.5
16
22
M10
16 mm
12.5
17
32
44
M12
18 mm
22
30
57
77
M16
24 mm
54
73
140
190
M20
30 mm
105
143
274
372
Specifications
C3e
General
Length
1040 mm
Width
520 mm
Height
1040 mm
Weight
55 kg
Motor
Type
Electric 2.2kW
Power source
Single phase 230-240V AC
50-60 Hz
8.4 A (S1)
Cutting System
Disc speed
2820 RPM
Disc dimensions
260 x 6 mm
Shaft diameter
24 mm
Knives
1
Feed System
Chipping capacity
40 mm
Feed type
Gravity fed, self-feeding
Inlet chute opening
100 x 130 mm
Discharge System
Discharge height
450 mm
Outlet chute type
Fixed
