Remove the knife for sharpening
Remove the inlet chute - use two 13 mm spanners to
remove the nuts and bolts holding the inlet chute on.
Tilt the chipper body so that the motor is resting on the
floor. Using a 13 mm spanner, remove the two smaller
bolts which hold the base onto the chipper body.
Open the cutting rotor housing by removing the four
housing bolts using two 16 mm spanners.
Using a nylon hammer (or suitable alternative), gently
dislodge the housing from its grooves and remove it.
