Receiving your Hansa chipper
You may receive your chipper assembled from your dealer or it may be packaged in two boxes. Assembly takes approximately 30
minutes, two people working together will make the assembly easier.
Chipper components
Note: Your Hansa C3e may not come with the chip catcher bag. The chip catcher bag must be purchased separately.
Tools required for assembly (not supplied)
• A knife to cut open the box
• Two 13 mm spanners - to tighten the inlet chute and wheels
• 18 mm spanner to attach the wheels
Box 1 contains:
✓ The chipper body
✓ Two wheels
✓ A cardboard block for support of the chipper body for wheel attachment
CAUTION: The chipper body weighs 42 kg; it is recommended to cut the box open rather than lifting the body out.
Box 1
Box 2
All the C3e parts in two separate boxes
