Hantek HDG6000B Series User Manual

User Manual 95
Distortion
Spurious signal
(non-hormonic)
Typical(0dBm)
≤10MHz：<-65dBc;
>10MHz：<-65dBc+6dB/octave
Phase Noise
Typical(0dBm,10KHz offset)
10MHz:≤-115dBc/Hz
Square
Rise/Down time
Typical (1Vpp)
<8ns
Typical (1Vpp)
<10ns
Typical (1Vpp)
<12ns
Overshoot
Typical (100KHz, 1Vpp)
<3%
Duty Cycle
≤10MHz: 10.0%~90.0%;
10MHz~40MHz: 40.0%~60.0%;
>40MHz: 50.0% (fixed)
Non-symmetry
1% of period+5ns
Jitter(rms)
Typical（1MHz,1Vpp, 50Ω）
≤5MHz: 2ppm+500ps;
> 5MHz: 500ps
Ramp
Linearity
≤1% of peak output (1KHz, 1Vpp)
Symmetry
0%~100%
Pluse
Period
20ns~1Ms
25ns~1Ms
40ns~1Ms
50ns~1Ms
Pulse
≥10ns
≥10ns
≥12ns
≥18ns
Leading Edge
Time
≥5ns
≥5ns
≥7ns
≥11ns
Overshoot
<3%(1Vpp)
Jitter(rms)
Typical (1Vpp)
≤5MHz 2ppm+500ps
> 5MHz 500ps
Arb. Wavefrom Generator
Waveform
Length
64M
Vertical
Resolution
16 Bit
Sample Rate
1.25GSa/s
Rise/Fall time
Typical(1Vpp):<6ns
Jitter
Typical (1Vpp)
≤5MHz 2ppm+500ps;
> 5MHz 500ps
Harmonic
