Hantek HDG6000B Series User Manual

User Manual 94
Appendix A Specifications
All technical specifications are applicable to HDG6000B(C) series signal generator. Unless
otherwise specified, all technical specifications are guaranteed when the following two conditions
are established.
 The signal generator is in the calibration period.
 The signal generator runs continuously for more than 30 minutes at the specified operating
temperature (18 ~28 C).
The specifications used are guaranteed except those marked "typical".
Model
HDG6202B(C)
HDG6162B(C)
HDG6112B(C)
HDG6082B(C)
Channel
2
2
2
2
Memory Depth
64M
64M
64M
64M
Maximum
Frequency
200MHz
160MHz
110MHz
80MHz
Sample Rate
1.25GSa/s
Voltage
Resolution
16Bit
Digital Output
16 Channels output
Waveforms
Standard
Waveforms
Sine, Square, Ramp, Pulse, Noise, Harmonics
Arbitrary
Waveforms
More than 160 kinds, including Sinc, Exponential Rise, Exponential Fall, ECG,
Gauss, Haver Sine, Lorentz, Dual-Tone, DC, etc.
Frequency Characteristics
Sine
1uHz~200MHz
1uHz~160MHz
1uHz~110MHz
1uHz~80MHz
Square
1uHz~60MHz
1uHz~50MHz
1uHz~40MHz
1uHz~35MHz
Pulse
1uHz~50MHz
1uHz~40MHz
1uHz~25MHz
1uHz~20MHz
Ramp
1uHz~5MHz
1uHz~4MHz
1uHz~3MHz
1uHz~2MHz
Noise
120MHz
120MHz
110MHz
80MHz
Harmonics
1uHz~100MHz
1uHz~80MHz
1uHz~55MHz
1uHz~40MHz
Arb.
1uHz~50MHz
1uHz~40MHz
1uHz~25MHz
1uHz~15MHz
Resolution
1uHz
Accuracy
±2ppm, 18~28℃
Sine Wave Spectrum Purity
Harmonic
Distortion
Typical（0dBm）
DC-1MHz: <-60dBc;
1MHz-10MHz: <-55dBc;
10MHz-100MHz: <-50dBc；
100MHz-200MHz: <-40dBc
Total Harmonic
<0.1% (10Hz-20kHz, 0dBm)

Hantek HDG6000B Series Specifications

General

Brand	Hantek
Model	HDG6000B Series
Category	Pulse Generator
Language	English
