Hantek HDG6000B Series User Manual

User Manual 100
Pulse Width
Resolution
8ns
Duty Cycle
Range (Display)
0% to 100%
Input Characteristics
Input Range
Breakdown Voltage
±5Vac+dc
Impedance=500Ω
Input Trigger
Trigger Level Range
-2.5V to +2.5V
Trigger Sensitivity Range
0% (140mV hysteresis voltage) to 100% (2mV hysteresis
voltage)
Trigger Characteristics
Trigger Input
Level
TTL-compatible
Slope
Rising or falling (selectable)
Pulse Width
>50ns
Clock Reference
External Reference Input
Lock Range
10MHz±50Hz
Level
2.5Vpp to 5Vpp
Lock Time
<2s
Impedance
(Typical)
5kΩ, AC coupling
Internal Reference Output
Frequency
10MHz ± 50Hz
Level
3.3Vpp
Impedance
(Typical)
50Ω, AC coupling
Sync Output
Level
TTL-compatible
Impedance
50 Ω, nominal value
General Specifications
Interface
HDG6000B: USB Host, USB Device
HDG6000C: USB Host, USB Device, LAN, Wi-Fi, Optional RS232
Display
7‟‟ 64K Color TFT Display, 800*480
Power Voltage
100-240V, 45Hz - 440Hz
Power
Consumption
<50W
Fuse
T, 3.15A, 250V, 5x20mm
