HARD 1935 - Gatch Extender Parts Identification

GATCH EXTENDER PARTS IDENTIFICATION
The Gatch Extender is a metal plate that extends outwards as the head of the crib is
raised to close the gap on the head end and help prevent potential entrapment hazards.
Components of the Gatch Extender:
#3- Extender Plate
#5- Bracket Assembly
#4- Sleeve Assembly
#2- Right
Gatch Weld
Assy
#2- Left
Gatch Weld
Assy
#10- 1/4-20x5/8” Screw
#6- 1/4-20x1/2 Lock Nut
#11- Washer
#9- 1/4-20x5/8” Screw
#11- Extender Caplug
#8- 1/4-20x1/2” Bolt
10
