SHELF & BUMPERS PARTS LIST
1
7
8
5
66
9
10
9
10
2
3
4
11
# Part Description Part # Qty Notes
1
Under Crib Shelf with O2 cut outs- 1935 88163 1
Complete shelf with hardware.
Does not include bumpers or hard-
ware for bumpers.
Under Crib Shelf with O2 cut outs- 1943 88164 1
Under Crib Shelf with O2 cut outs- 1955 88165 1
Under Crib Shelf with O2 cut outs- 1975 88166 1
2 Screw 1/4-20x5/8 63392 4
Used to attach shelf to bumper3 Jam Nylon Locknut 1/4-20 63413 4
4 Washer 1/4 63443 4
5
Bumper Assembly- 1935, 1943 84128 2
Assembly includes #6, 7 & 8
only with bumper plate
Bumper Assembly- 1955, 1975 84126 2
6 Grey Corner Bumpers 63896 4
7 Screw 8-32x7/8 60129 8
For grey corner bumper
8 K-Nut 8-32 60139 8
9 Button Socket Cap Screw 1/4-20x7/8 60242 6
Used to attach bumper
to the crib
10 Connector Nut 1/4-20 60245 6
11 “NO STEP” Sticker 62180 2
Position: middle of both of the long
sides of the shelf
To Next Page
