GATCH EXTENDER PARTS LIST
*Note- On older Springfi eld Crib models, the Extender Plate was larger and the tabs
on the left and right weld assemblies were longer than the current version pictured
in this document. Please call or email for pricing on those older components.
# Part Description Part # Qty# Notes
1
Gatch Extender Assembly-
30” wide crib
93260 1
Complete assembly with all hardware.
Specify color when ordering
Gatch Extender Assembly-
36” wide crib
93261 1
2
Gatch Weld Assembly- Left 89803 1
Newer version-
Specify color when ordering
Gatch Weld Assembly- Right 89804 1
3
Extender Plate- 30” wide crib 12290 1
Specify color when ordering
Extender Plate- 36” wide crib 12291 1
4 Sleeve Assembly 81367 2
The left and right Gatch weld assemblies
slide into this part which is mounted on the
underside of the head pan.
5 Bracket Assembly Hardware Bag 72045
1
pair
Brackets which glide up and down head end
corner posts. Includes #7 & 8 to attach to
weld assemblies
6 1/4-20 Lock Nut 63413 8
4 used on sleeve assemblies,
4 used to attach extender plate to
Gatch weld assemblies
7 Washer 63443 2
Used to attach the bracket assembly
to the Gatch weld assemblies
8 1/4-20x1/2” Bolt 60128 2
9 1/4-20x5/8” Screw 60157 4
Used to attach extender plate to
weld assemblies
10 1/4-20x5/8” Screw 63392 4
Used to fasten sleeve assembies to the
head pan
11 Extender Caplug 63236 2
Cover for the open end of the
Gatch weld assemblies
To Next Page
