MODEL M6 17
OPERATIONAL PROCEDURE
Spreading Fill and Topsoil
Position so it is tilted on gauge wheels, since depth of cut is not the objective. Endplates can be
installed and the windrow angle set as needed to control the material movement.
Changing Grade
Grade modication can be accomplished during nish grading by angling the rake to collect and
windrow the maximum amount of material toward targeted areas.
Thatching Existing Grass Areas
The prime mover attachment plate should be tilted forward to support the rake on the front gauge
wheels and toothed roller raised so teeth are just grazing the surface. Travel speed should be
slow and careful.
Shutting Down
Stop engine.
Lower the lift arms and power rake to the ground.
Purge any air in the system. Hydraulic system leak down, hydraulic system failures, mechanical
failures, or movement of control levers can cause equipment to drop or rotate unexpectedly.
Shut off engine, set brake, remove key, remove seat belt, and release operator restraint before
leaving the prime mover operator’s seat.
Install endplates on attachment side of power rake as shown in Figure 7 (page 18).
On a hard level surface, lower attachment to the ground.
Shut off engine, set brake, remove key, remove seat belt, and release operator restraint before
leaving the prime mover operator’s seat.
Move attachment coupler latches to the unlocked position (lockpins must be disengaged).
Disconnect hydraulic hoses from quick couplers. Install dust plugs and couple hoses together for
storage. Disconnect direction control switch from prime mover power cord and remove switch.
Move to prime mover seat and start engine. Release brake and roll attachment coupler until it is
disengaged from the attachment. The attachment should rest in a stable position for storage.
STORAGE
Make sure the disconnected power rake is stored on a hard, level surface. Endplates mounted
on attachment side of rake increase stability.
Block equipment securely for storage.
Keep children and bystanders away from storage area.
