Harley M6 - Assembly - Main Part List

MODEL M6 41
ITEM QTY PART NO. DESCRIPTION
1 1 M16157PG Barrier Mount
2 2 M6427 Barrier
3 2 M6428PG Barrier Strap
4 1 M6624PG Right End Gate
5 1 M6625PG Left End Gate
6 1 M8624PG Chain Case Cover
7 1 M8626 Cover Seal
8 1 P278001 Breather Plug
9 1 P481010 Bushing Spacer
10 2 M6442 3/4” X 2-7/8” Gate Pin
11 2 P622600 Hair Pin Clip
12 1 P500300 1/4” O-Ring Washer
13 1 P500302 1/4” Rubber Face Washer
14 2 M18188 5/8” U-Bolt Strap
15 1 M5009-5 3/16” X 1/2” X 1-3/4” Washer
16 16 P155350 5/16” Top Lock Nut
17 4 P157500 5/8” Top Lock Nut
18 2 P157200 1/2” Hex Jam Nut
19 4 P157501 5/8” Nylock Nut
20 1 P100406 1/4” X 1-1/2” Hex Bolt
21 16 P104506 5/16” X 1-1/2” Carriage Bolt
22 1 P100804 1/2” X 1” Hex Bolt
23 2 P127110 1/2”-13 U-Bolt
24 2 P128440 5/8” X 4” X 4-1/4” U-Bolt
25 2 P128410 5/8” X 2” X 7-1/4” U-Bolt
26 1 P970003 Decal: Lubrication
27 1 P975807 Decal: Harley
28 1 P976500 Decal: Lift Hook
29 1 P975935 Decal: M6 Chain Case Cover
30 1 P851108 1/2”-13 Lock Washer
31 2 RDL3131 Tape, Refective, Red, 2 x 6
32 2 RDL3132 Tape, Refective, Amber, 2 x 6
ASSEMBLY - MAIN PART LIST
