MODEL M6 43
ITEM QTY PART NO. DESCRIPTION
1 1 P756160 Wheel & Tire
1A 1 M16107 Wheel, Tire, & Hub
2 1 M6817PG Caster Fork
3 1 M16153PG Caster Support Arm
4 1 M16011 Caster Shaft
5 1 M6415PG Handle
6 1 M16158 Wheel Hub W/Studs
6A 1 M16120 Wheel Hub Complete
7 1 M16108 Axle Spacer Long
8 1 M16109 Axle Spacer Short
9 2 P760300 Bearing Cone
10 2 P760500 Bearing Cup
11 2 P762200 1” Bearing Cone
12 2 P756163 Grease Seal
13 2 P852200 Felt Washer
14 1 M6223 3/16” X 1/2” X 3” Washer
15 1 P850620 1/4” Flat Washer
16 1 M5009-5 3/16” X 1/2” X 1-3/4” Washer
17 1 P851108 1/2” Lock Washer
18 1 P852608 1/2” Hard Washer
19 2 P620200 1/4”-28 Straight Grease Fitting
20 1 P158006 1/2”-13 Slotted Hex Nut
21 4 P756165 1/2”-20 Wheel Nut
22 1 P158000 3/4”-16 Slotted Hex Nut
23 1 P116204 1/8” X 1” Cotter Pin
24 1 07-1044 5/32” X 1-1/2” Cotter Pin
25 1 M10463 3/4” X 9-1/2” Axle Bolt
26 1 P100804 1/2” X 1” Hex Bolt
27 1 P102808 1/2” X 2” Fine Thread Hex Bolt
ASSEMBLY - CASTER WHEEL PARTS LIST
