Harley M6 - Assembly - Angle Hydraulics Parts List

MODEL M6 45
ITEM QTY PART NO. DESCRIPTION
1 1 P243506 50 Gpm Hydraulic Manifold
1A 1 P243501 Solenoid Cartridge
1B 2 P243505 Solenoid Coil
2 1 03-5728 Hydraulic Cylinder (Serial # 1020400 & Up)
1 P257600 Hydraulic Cylinder (Serial # 1019499 & Down)
3 2 P246135 -4 Hose X 34” 6FJX-6FJX
4 4 P277100 Adapter 16MB-12MJ
5 4 P276450 Adapter 12MJ-12MB
6 2 P255716 -10 Hose X 56” 12FJX-12FJX90
°
7 2 P255737 -10 Hose X 68” 12FJX-12FJX90
°
8 1 P272670 Female Flat Face Coupler
9 1 P272671 Male Flat Face Coupler
10 1 M16159 Switch Assembly (Serial # 1126499 & Down)
11 4 P261350 Elbow 6MB-6MJ90°
12 1 M6726 Cable Assembly (Serial # 1126499 & Down)
13 2 P620200 1/4”-28 Straight Grease Fitting
14 1 07-7733 Wire Harness, Power Lead, 126 inches (Serial # 1127400 & Up)
15 1 07-7734 Wire Harness, with Box (Serial # 1127400 & Up)
16 1 07-7737 Wire Harness, 108 inches, for Solenoid (Serial # 1127400 & Up)
ASSEMBLY - ANGLE HYDRAULICS PARTS LIST
