MODEL M6 37
ASSEMBLY - ROLLER FRAME PARTS LIST
ITEM QTY PART NO. DESCRIPTION
1 1 M16048PG Main Frame
2 1 M16045PG Carbide Tooth Roller
3 1 M8609PG Chain Case
4 1 M8241PG Lower Cover
5 1 M8272 Cover Tab
6 1 P350200 Hydraulic Motor
7 1 P015307 1-1/2” Bearing Cap
8 1 P015308 1-1/2” Non-Locking Collar
9 1 P015309 1-3/4” Non-Locking Collar
10 1 M6573 1-1/2” Cylindrical Bearing Assembly
- 1 P015210 1-1/2” Cylindrical Housing
- 1 P010401 1-1/2” Bearing Insert
11 1 M6574 1-3/4” Cylindrical Bearing Assembly
- 1 P015215 1-3/4” Cylindrical Housing
- 1 P012201 1-3/4” Bearing Insert
12 2 M6628 Idler Roller
13 2 M16113 Tension Arm
14 2 M6630 Tension Bushing
15 1 P652200 Sprocket 50-2, 22 Tooth 1-1/4” Spline
16 1 P652201 Sprocket 50-2, 22 Tooth 1-3/4” Spline
17 1 M8636 Chain 50-2, 93 Pitch
18 1 P500202 3/32” X 4-3/4” O-Ring
19 1 P500203 3/8” X 2-5/8” O-Ring
20 1 P604800 Extension Spring
21 1 M8637 Collar
22 2 M16056 Sleeve
23 1 P116306 3/16” X 1-1/2” Cotter Pin
24 1 P855120 10 GA X 1-1/4” Machine Bushing
25 2 P855128 10 GA X 1-3/4” Machine Bushing
26 1 P855320 14 GA X 1-1/4” Machine Bushing
27 1 P855328 14 GA X 1-3/4” Machine Bushing
28 3 P500300 1/4” O-Ring Washer
29 2 P851104 1/4” Lock Washer
30 1 P851106 3/8” Lock Washer
31 1 P851108 1/2” Lock Washer
32 1 M14038 3/8” X 2” OD Washer
33 4 P850609 9/16” Flat Washer
34 2 P952224 5/8” Heavy Snap Ring
35 3 M5464 1” Id X 2-1/4” OD Washer
36 2 P155350 5/16” Center Lock Nut
37 1 P155450 3/8” Top Lock Nut
38 4 P155851 1/2” Top Lock Flange Nut (GR8)
LIST 1 OF 2
