Harman Kardon AVR 1510S User Manual

36
AVR
Appendix
Surround Mode Description Incoming Bitstream or Signal
Dolby Digital Provides up to five separate main audio channels and a dedicated low-frequency
effects (LFE) channel.
• Dolby Digital 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1,
2/1/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1
• Dolby Digital EX (played as 5.1)
• Dolby Digital Plus decoded and delivered via coaxial or optical
connection
Dolby Digital EX An expansion of Dolby Digital 5.1 that adds a surround back channel that may be
played through one or two surround back speakers. May be manually selected when a
non-EX Dolby Digital stream is detected.
• Dolby Digital EX
• Dolby Digital 2/2/.0 or .1, 3/2/.0 or .1
Dolby Digital Plus An enhanced version of Dolby Digital encoded more efficiently, Dolby Digital Plus has
the capacity for additional discrete channels and for streaming audio from the Internet,
all with enhanced audio quality. Source material may be delivered via an HDMI
connection or decoded to Dolby Digital or PCM and transmitted via coaxial or optical
digital audio.
• Dolby Digital Plus via HDMI connection (source device decodes to
Dolby Digital when a coaxial or optical connection is used)
Dolby TrueHD Dolby TrueHD is an expansion of MLP Lossless
™
audio, the same format used on
DVD-Audio discs. Dolby TrueHD adds the features found in Dolby Digital, such as night
mode settings, while delivering fully lossless audio that is a true reproduction
of studio master recordings.
• Blu-ray Disc or HD-DVD encoded with Dolby TrueHD, delivered via
HDMI
Dolby Digital Stereo Delivers a two-channel downmix of Dolby Digital materials. • Dolby Digital 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1,
2/1/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1
• Dolby Digital EX
Dolby Pro Logic II Mode
Group
Analog decoder that derives five full-range, discrete main audio channels from matrix
surround-encoded or two-channel analog sources. Four variants are available.
See below
Dolby Pro Logic II Movie Variant of Dolby Pro Logic II that is optimized for movie and television programs. • Dolby Digital 2.0 or 2.1
• Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
Dolby Pro Logic II Music Variant of Dolby Pro Logic II that is optimized for music selections. Allows adjustment
of sound-field presentation in three dimensions:
• Center Width (adjusts width of vocal soundstage)
• Dimension (adjusts depth of soundstage)
• Panorama (adjusts wraparound surround effect)
• Dolby Digital 2.0 or 2.1
• Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
Dolby Pro Logic Variant of Dolby Pro Logic II that emphasizes use of the surround channels and
subwoofer for total immersion in the video gaming experience.
• Dolby Digital 2.0 or 2.1
• Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
Dolby Pro Logic II Game Original version of Dolby Pro Logic that steered a mono signal containing information
below 7kHz to the surround channels.
• Dolby Digital 2.0 or 2.1
• Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
Table A8 – Surround Modes

Harman Kardon AVR 1510S Specifications

General

Receiver type	Surround
Input sensitivity	250 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	38 dB
Total Harmonic Distortion (THD)	0.1 %
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Digital audio optical in	1
Speakers connectivity type	Binding post
Ethernet LAN	-
AM band range	522 - 1.62 kHz
FM band range	87.5 - 108 MHz
Internet radio	Yes
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Cables included	AC

Weight and Dimensions

Depth	300 mm
Width	440 mm
Height	121 mm
Weight	4600 g
