Harman Kardon AVR 745

Ref. Designator Part Number
Description
VIDEO PCB
D100 D101 D102 D103 D104
D105 D106 D107 D108 D109
D120 D121 D122 D123 D124
D125 D129 D143 D144
H03-DS1S50094NB-R D-SLP 1SS355 35.0V 225MI0A
IC56 IC57 IC61 IC62 H03-DSAMP0514MN-R DIODE TVS ARRAY RCLAMP0514M MSOP-10L
D126 D127 D128 H03-DSBAV99LTNB-R DIODE SWITCHINGBAV99LT1G SOT-23
IC50 IC51 IC53 H03-IC74A244PD8-R IC SN74ALVC244PWR TSSOP20 Octal Buffer/Driver With 3-State Outputs
IC66 H03-IC74CB3T3D2-R IC SN74CB3T3306DCTR SSOP-8 Dual Bus Switch Voltage Translator
IC40 H03-ICADA44106A-R IC ADA4410-6ACPZ Integrated Video Filter with Selectable Cutoff Frequencies for
GBR, HD/SD, Y, C, and CVBS
IC39 H03-ICADA44123A-R IC ADA4412-3ARQZ Integrated Triple Video Filter
IC29 H03-ICADV7320KS-R IC ADV7320LKSTZ 12-bit 216MHz Video Encoder with NSV and Macrovision®
Copy Protection
IC24 H03-ICADV7401EF-R ADV7401BSTZ-110 LQFP100 10-Bit, Integrated, Multiformat SDTV/HDTV Video
Decoder
IC12 IC42 IC45 IC59 H03-ICBU4053BB4-R IC BU4053BCF SOP16 Triple 2-channel analog multiplexer / demultiplexer
IC18 IC19 1C20 IC21 IC22 H03-ICBU4094BD3-R IC CMOS BU4094BCF SOP16 8-bit compatible shift / store register
IC65 H03-ICCJT1172N5-R CJT1117-2.5 SOT-223 1A LOW DROPOUT LINEAR REGULATOR
IC11 H03-ICCJT1173N3-R IC VOLTAGE REGULATOR CJT117-3.3 SOT-223
IC43 IC46 H03-ICEEP24LCD2-R 24LC08BT-I/SNG SOIC-8P MICROCHIP SERIAL EEPROM
IC47 H03-ICFLI2300NN-R IC VIDEO ENHANCER FLI2300-BD PQFP-208
IC27 H03-ICLC74763ME-R LC74763M-9602-E SOP30 On-Screen Display LSI
IC17 IC25 IC26 IC33 IC34 IC35
IC36 IC37
H03-ICM1503XNRE-R MM1503XNRE SOT-26B Video Switch 75 driver Y/C mix
IC32 H03-ICMM1511XDL-R IC-VIDEO SW MM1511XNRE SOT-26B Video Switch 75 driver Y/C mix
IC13 IC14 IC15 IC16 H03-ICNJM2296D3-R IC-LINEAR NJM2296M-TE1 5-INPUT 3-OUTPUT VIDEO SWITCH
IC38 H03-ICNJM2586MN-R IC VIDEO AMP NJM2586M-TE1 DMP24
IC55 H03-ICSII903144-R IC SIL9031CTU TQFP144 Dual input HDMI Receiver w/6/8 - channel audio
(480p/720p/1080
IC54 H03-ICSIL903080-R PanelLink CinemaTransmitter SII9030CTU TQFP80
IC23 IC28 IC31 H03-ICTSH95IDB4-R IC-VIDEOPROC TSH95ID VIDEO AMPLIFIER
Q119 Q120 H03-TR2N7002LND-R MOSFET N-CHANNEL 2N7002LT1G SOT-23
Q101 H03-TRKTC3875ND-R TRANSISTOR NPN KTC3875S SOT23 NPN
Q110 Q111 Q112 Q123 H03-TSKRA107SNI-R KRA107S SOT-23 PNP
Q103 Q104 Q105 Q106 Q113
Q114 Q115 Q118
H03-TSKRC107SND-R KRA107S SOT-23 PNP
IC41 IC44 IC58 H03-TSUPA672TNH-R TRANSISTOR MOSFET N-CHANNEL UPA672T-T1-A SMD
IC10 H03-ICIL1117SDG-R IC LOW DROP REGULATOR IL1117S-1.8 1.8V SOT-223
IC48 H03-ICK4S6432I6-R IC 64M SDRAM K4S643232H-UC60/70 64Mb H-die (x32) SDRAM
IC67 IC68 H03-ICC1G125DCK-R IC SINGLE BUS BUFFER GATE SN74LVC1G125DCKT SOT(SC-70)DCKT
Resistors
R191 R192 RS1AD0750NA-R RES CHIP 75OHM 1% 1/16W 0603
R153 RS1AD1691NA-R RES CHIP 1K69 ohm 1/16W 1% 0603
R318 RS1AD1870NA-R RES CHIP 187 OHM 1/16W 1% 0603
R288 R291 R294 R298 R301
R302 R304 R357
RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R358 R359 RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
R251 R255 R258 R371 RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R164 R223 R224 R225 R308
R309
RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R173 R174 R317 R334 RS3AD0105NA-R RES CHIP 1M 1/16W +5% 0603
R230 R231 RS3AD010ANA-R RES CHIP,1R 1/16W +/-5%,0603
R126 RS3AD0123NA-R RES CHIP,12K 1/16W +/-5%,0603
R165 RS3AD0152NA-R RMGCFMIC 1K5 OHM +5% 0603
R252 R253 R256 R259 RS3AD0153NA-R RES CHIP,15K 1/16W,+/-5%,0603.
R339 RS3AD0201NA-R RES.CHIP,200 1/16W +-5%,0603.
R261 R263 R397 RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R151 R152 RS3AD0272NA-R RMGCFMIC 2K7 OHM +5% 0603
R368 RS3AD0302NA-R RMGCFMIC 3K0 OHM +5% 0603
R335 RS3AD0330NA-R RMGCFMIC 33R0 OHM +5% 0603
R260 R262 R396 RS3AD0333NA-R RMGCFMIC 33K0 OHM +5% 0603
R369 RS3AD0390NA-R RES,CHIP 39 OHM 1/16W +/-5% 0603
R206 R336 R394 RS3AD0470NA-R RMGCFMIC 47R0 OHM +5% 0603
AVR745
harman/kardon
124
