Harman Kardon AVR 745

Ref. Designator Part Number
Description
VIDEO PCB
R208 R282 R283 R319 R333
R345 R346 R381 R382
RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R400 R401 R402 R403 RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R247 R250 RS3AD0680NA-R RMGCFMIC 68R0 OHM +5% 0603
R370 RS3AD0681NA-R RES CHIP,680R 1/16W +/-5%,0603
R163 RS3AD0682NA-R RMGCFMIC 6K8 OHM +5% 0603
R254 R257 RS3AD0752NA-R RES CHIP 7.5K,1/16W,+-5%,0603.
R391 RS3AD0822NA-R RMGCFMIC 8K2 OHM +5% 0603
RV16 RV17 RV18 RV19 RV20
RV21 RV22 RV23
H03-VR0402V275R-R VARISTOR CHIP CT0402V275RFG 16V
RV10 RV11 RV12 RV13 RV14
RV15
H03-VR0603V150R-R VARISTOR CHIP CT0603V150RFG
RA30 RA31 RA32 RN3AY0220NA-R RES NETWORK RCA 22OHM 1/16W 5% CN34JT220
R100 R101 R102 R103 R105
R106 R107 R108 R109 R110
R111 R189 R190 R217 R218
R219 R233 R237 R238 R239
R240 R241 R242 R243 R244
R245 R246 R267 R268 R269
R270 R271 R272 R273 R274
R275 R277 R278 R279 R324
R325 R326 R327 R328 R329
R383 R384 R385 R386 R387
R388
RS1AD0750NA-R RES CHIP 75OHM 1% 1/16W 0603
R332 RS1AD4750NA-R RES.CHIP 475 OHM 1/16W +/-1% 0603
R104 R209 R210 R211 R232
R234 R235 R236
RS1AD787ANA-R RES CHIP 78.7 ohm 1/16W 1% 0603
R181 R286 R292 R296 R355
R367
RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R406 RS3AD0100NA-R RMGCFMIC 10R0 OHM +5% 0603
R168 R177 R178 R179 R180
R322 R323 R330 R331 R340
R341 R378 R379
RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
R123 R124 R125 R127 R128
R129 R131 R132 R133 R135
R136 R137 R139 R140 R141
R160 R161 R170 R171 R172
R347 R351
RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R144 R145 R146 R159 R169
R212 R213 R214 R220 R221
R222 R310 R311 R312 R313
R314 R315 R316 R321 R342
R349 R350 R353 R354 R360
R361 R398
RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R154 R155 RS3AD0105NA-R RES CHIP 1M 1/16W +5% 0603
R112 R113 R114 R115 R116
R117 R118 R119 R120 R121
R122 R147 R148 R157 R158
R184 R185 R215 R216 R226
R227 R228 R229 R264 R265
R266 R276 R389 R390
RS3AD010ANA-R RES CHIP,1R 1/16W +/-5%,0603
R162 R187 R188 RS3AD0121NA-R RMGCFMIC 120R0 OHM +5% 0603
R130 R134 R138 R142 RS3AD0123NA-R RES CHIP,12K 1/16W +/-5%,0603
R167 RS3AD0124NA-R RES CHIP,120K 1/16W +/-5%,0603
R150 RS3AD0154NA-R RMGCFMIC 150K0 OHM +5% 0603
R343 R344 RS3AD0182NA-R RES CHIP,1.8K,1/16W,+-5%,0603.
R248 RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R348 R352 RS3AD0223NA-R RES CHIP,22K 1/16W +/-5%,0603
R166 RS3AD0224NA-R RES CHIP,220K 1/16W +/-5%,0603
R149 RS3AD0271NA-R RMGCFMIC 270R0 OHM +5% 0603
R186 R372 R373 R374 R375
R376 R377
RS3AD0301NA-R RES,CHIP 300 OHM 1/16W +/-5% 0603
R365 RS3AD0302NA-R RMGCFMIC 3K0 OHM +5% 0603
R407 R408 RS3AD0330NA-R RMGCFMIC 33R0 OHM +5% 0603
R249 RS3AD0333NA-R RMGCFMIC 33K0 OHM +5% 0603
AVR745
harman/kardon
125
