Harman Kardon AVR 745

Ref. Designator Part Number
Description
VIDEO PCB
R182 R183 R207 R320 R362
R380 R409 R410
RS3AD0470NA-R RMGCFMIC 47R0 OHM +5% 0603
R175 R176 R280 R281 R284
R285 R337 R338 R364
RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R156 RS3AD0624NA-R RES,CHIP 620K 1/16W +/-5% 0603
R395 RS3AD0680NA-R RMGCFMIC 68R0 OHM +5% 0603
R392 R411 RS3AD0682NA-R RMGCFMIC 6K8 OHM +5% 0603
R404 R405 RS3AD068ANA-R RES, CHIP, 6.8 OHM 1/16W, +/-5% 0603
R143 RS3AD0822NA-R RMGCFMIC 8K2 OHM +5% 0603
RA10 RA11 RA12 RA13 RA16
RA17 RA18 RA19 RA22 RA33
RA34 RA35 RA36 RA39
RS3AY0470NA-R RES NETWORK RCA 47R0 OHM +5% 62M15W CN34JT470
Miscellaneous
L100 L130 L131 L132 L133
L134 L135 L136 L137 L138
L139 L140 L141 L146
H03-FB1212012KF-R FCM2012KF-121T08 120ohm 2012
L110 L112 H03-FB2012F1R5K-R FCI2012F-1R5K 1.5UH 0805
L105 L106 L107 L108 L114
L115 L116 L118 L119 L120
L123 L124 L125 L126 L127
L128 L129 L154
H03-FB2012F3R9K-R FCI2012F-3R9K 3.9UH 0805
L111 L113 H03-LS2012F1R8K-R INDUCTOR COIL FCI2012F-1R8K 1.8UH 0805
L142 L143 L144 L145 H03-LS2012H9002-R CHOKE COIL ACM2012H-900-2P
NJ17 NJ18 NJ19 H03-SOYKF457009-R YKF45-7009
F100 H03-SWNANDC1502-R SWITCH POLY NANOSMDC150F-2 SMD
L101 L102 L103 L121 H03-FB05B3580NN-R BEAD AXIAL/TAP,HC3580 80.5ohm
L122 H03-LAINB0470CR-R LF 47U0H +10% 5.8 OHM 500MI0A
L109 H03-LALNB056ACR-R INDUCTOR COIL AL02TB5R6J 5.6UH 1.9OHM +5%
Y103 H03-OSX13M5HZ00-R CRYSTAL 13.5MHz WOOIN
Y100 H03-OSXBE14M3AU-R CRYSTAL 14.31818MHz WOOIN
Y101 H03-OSXBE17M7AU-R CRYSTAL 17.734475MHz WOOIN
Y104 H03-OSXBE28M39S-R CRYSTAL28.322MHz 18pF HC-49/S
K100 K101 K102 K103 H03-RLL0517811A-R RELAY D3009(1-1462033-4)
NJ16 H03-SOR12BJ12GN-R JACK RCA 12P BJ120154JG R4 BU4 G4,GOLD COLOR
NJ10 NJ12 NJ11 NJ13 NJ14
NJ15
H03-SORA60031GN-R JACK RCA+S-VIDEO 6P C80300312G,GOLD COLOR
P602 H03-WN04AB00000-R CONN 2.0MM GIL-S-04P-S2L2-EF 4P
P700 P701 H03-WN04AB100WH-R CONN WAFER 2.0MM 4P 35237-0410 WHT
N700 N701 H03-WN04SB100WH-R CONN WAFER 2.0MM 4P 35336-0410 WHT
P604 H03-WN05AB00000-R GIL-S-05P-S2L2-EF 5P
P601 H03-WN06AB00000-R CONNECT 2.0mm 6P GIL-S-6P-S2L2-EF
P603 H03-WN07AD00000-R CONNECT WAFER 2.5MM 7P 5268-07A WHT ANGLE
P702 H03-WN10AB000WH-R CONNECT WAFER 2.0mm 10P 35237-1010 WHT
N702 H03-WN10SB100WH-R CONNECT WAFER 2.0mm 10P 35336-1010 WHT
N611 H03-WN16AI00000-R CONNECT 1.25MM 16P GF120-16S-LS 1.25MM 16P
P612 H03-WN18DI00001-R GF120-18S-LS 1.25mm 18P
P605 H03-WN29AI00000-R CONN 1.25MM 29 FE R WH GF120-29S-LS 2794 A6
Y105 H03-OSX27MSCOB0-R CRYSTAL,27.000MHz SCO-103 25-27.000M
C540 CZJII0820BE-R CAPACITOR CERAMIC/CHIP ,82pF 50V CH J NP0 0603
MECHANICAL ASSEMBLY
H03-SWA2B21PDA&-R SW PUSH POWER SDDLB15700
H03-TXPWMEINAB0-R POWER TRANSFORMER AVR745 MAIN TRANS 120V 60Hz USA ONLY
H03-TXPWMEI96B0-R POWER TRANSFORMER AVR745EU MAIN TRANS 230V 50Hz
H03-WF22S2605RT-R DHCDT-22/260-P1.25-RT(5/5,10/10)
H03-WG02SG8532A-R WIRECONASY UNIQUE 2P 530MM UL1617 PVC DOUBLE INSULATED
H03-WG04SB81400-R UL1007#26 STR 140mm 2.0mm 4P WHT
H03-WN16SI01200-R WIRE FCC CABLE DHCDT-16/120-P1.25-ST(5/5,10/10) G2,Shield
H03-WN18SI03600-R WIRE FFC (CARD CABLE)DHCDT-18/360-P1.25-RT(5/5,10/10)
H03-WN29SI02000-R WIRE FFC (CARD CABLE)DHCDT-29/200-P1.25-ST(5/5,10/10)
H03-ZMB01S00100-R BKT HEADPHONE
H03-ZMB01S02200-R SPRING PLATE GND C5212 0.2T
AVR745
harman/kardon
126
