Vi1000 USER MANUAL
16.5 16.5: MENU > TIELINES
16.5: MENU > TIELINES
Tie Line Input
Patch Active
Assign a physical input to this Tie Line.
The Red INPUT buttons open
an input assign page in the
main touch screen area where
you can choose any available
console input.
Input Patch
Screen
Tie Line Output
Patch Active
Assign a physical output to this Tie Line.
The Red OUT buttons open
an output assign page in the
main touch screen area wher
eyou can choose any available
console output.
Output Patch
Screen
Tie Line Label Active
Dene a custom label for the Tie Line.
The Tie Line Label buttons open
up a text entry screen in the
main touch screen. You can also
use an external USB keyboard.
Text Entry
Screen
