6.2 6.2: INPUT CHANNEL > CHANNEL STRIP
Vi1000 USER MANUAL
6.2: INPUT CHANNEL > CHANNEL STRIP
The Input Channel Strip
Input Channel
Strip Encoder Field / Group: Range Low Range High
Rotary control whose
function is dened by
the input ENCODER
MODE buttons.
The Default function is control over the channel’s
analogue input gain.
For more information see the Inputs Encoder Mode refer-
ence section 6.3
Dependant
on Mode
Dependant on
Mode
Input Channel
Strip F Field / Group: Active Inactive
User-dened button
whose function is
dened in the
Menu-Settings page
The function can be chosen between Input A/B selection
(duplicating the Input A/B switch in the Input Vistonics
page), or Strip Lock function (allowing input strips to be
locked in position against layer changes).
Input B
selected, or
Strip Lock
enabled
Input A
selected, or
Strip Lock
disabled
