ASSEMBLY PARTS
ITEM
QTY
PART NO. DESCRIPTION
11 240-3C01-AA HYBRID INNER TOWER VERTICAL ASSEMBLY
21 251-ZC01-CA HPL MIDDLE CAR ASSEMBLY
31 253-ZC01-CA LOWER CAR ASSEMBLY
41 256-ZC01-CA HYBRID AXLE ASSY LEFT
51 257-ZC01-CA HYBRID AXLE ASSY RIGHT
61 502-ZC01-CA HYBRID TOP LIMIT PLATE
71 503-ZC01-CA HYBRID TOP LIMIT ADJUSTMENT
81 579-ZC01-CA HYBRID STRAP MOUNTING PLATE
91 ALA50006C U-BOLT BACKING PLATE
10 8 ALA60061 ROLLER
11 1 ALA6789 BACKING PLATE RUBBER, 1" BLACK, ADHESIVE
12 2 BHCS-0_25-20--0_50 BUTTON HEAD 1/4-20 x 0.50
13 8 FHMS-0_25-20--0_75-NP-Z FLAT HEAD w/PATCH 1/4-20 X 0.75
14 2 HHCS-0_25-20--0_75-Z HEX HEAD 1/4-20 x 0.75
15 2 NUT-0_25-20-NYLOCK-Z NYLOCK NUT 1/4-20
16 8 NUT-025-20-HEX-Z NUT, HEX, 1/4-20, ZINC PLATE
17 2 RHMS-0_25-20--0_25-Z ROUND HEAD 1/4-20 X 0.25
18 2 SHCS-0_25-20--0_25-Z SOCKET HEAD 1/4-20 x 0.25
19 2 SHSB-0_25--0_25-SS SHOULDER BOLT 1/4 SHAFT X 0.25
20 2 WASH-0_25-0_50--0_06-SL-Z SPLIT LOCK WASHER 1/4
