Harmar Mobility AL600 - AL600 Platform Parts List & Assembly

TEC0020 2018JAN3 P/N: 630-00025 Rev D AL600 & AL690 Hybrid Installation & Owner's Manual
| www.harmar.com | 800-833-0478
52
Exploded Views
SECTION 2 : INSTALLER
AL600
PLATFORM ASSEMBLY PARTS LIST
ASSEMBLY PARTS
ITEM
QTY
PART NO. DESCRIPTION
11 271-ZC01-CA HPL PLATFORM 22 400-ZC01-AA INSERT, SQUARE, 1.25, BLACK PLASTIC
34 ALA69073PIONEER STRAP ASSEMBLY
44BHCS-0_37-16--0_75-SS BUTTON HEAD 3/8-16 x 0.75 54NUT-0_37-16-NYLOCK-Z NYLOCK 3/8-16
