1. Locate both sets of screws with plasc knob, washers
and plasc encased inner bolts in the hardware bag
and set aside.
2. Locate the 0.5 inch (1.2 cm) screw and washer in the
hardware bag and set aside.
3. Idenfy the 8.8 inch (22.3 cm) backrest connector
rod pre-installed in base of backrest. Remove and set
aside.
4. Connect the backrest to the base in the upright
posion, ensuring that the backrest inserts snugly
around the outside of the armrest grooves.
: Stretch backrest extensions
out slightly to help guide them
around the armrest grooves.
5. Insert screw, washers (x2) and inner
bolt as indicated in each armrest
❶. Ensure that the bolt is properly
aligned with the indentaon ❷.
Secure assembly by turning screw
clockwise unl ght ❸.
: If screws do not pass through
easily, make sure that the screw
holes are aligned and tap screw
head lightly to guide it through
the armrest plasc.
6. Turn the child restraint over and
slide the base plate between
the two backrest anchor points.
❸
❶
❷
21
