4.2.2.2. Instrument panel (2)
The tractor is available an İnstrument pane.
Infoline − instrument panel:
Infoline − instrument panel is equipped with a
mechanical hour meter
4.2.2.2.1. Fuel gauge
The fuel level warning light (5) comes on, when
about 14 l of fuel is left. To prevent formation of
condensation, it is recommended that the tank
should be kept full.
4.2.2.2.2. Tachometer (4)
The tachometer (rev. counter) shows the engine
speed in hundreds of revolutions per minute.
4.2.2.2.3. Coolant thermometer (1)
The white zone shows the limits for the normal
operating temperature. Stop the engine if the needle
moves into the red zone.
4.2.2.2.4. Indicator lights for direction
indicator (2)
There is an indicator light for the right and left
direction indicators.
4.2.2.2.5. Indicator light for main
beam(5)
This indicator light comes on, when the main beam
is on
.
