HATTAT A90 - Pto; Power Take off Output; PTO Speeds at Different Engine Revs; Powered Front Axle

78
PTO
PTO Speeds...................... ……………………… 540/540E (750) rpm (A70, A80)
PTO Speeds ......................……………………… 540/1000 (A90, A100. A110)
PTO-shaft, ISO 500 -1979 Z6 ...............................ø 35 mm
Control………………………………………………2 PTO speed,selected by lever, seperated from real clutch
Power take off output
Tractor Models
A70,
A70L
A80
A80L
Turbo
A90 A100 A110
Max. power take---off output (kW), at nominal
revs of 540 r/min (engine speed 1890 r/min)
40.3 46.8 44.4 49 55 60
PTO speeds at different engine revs.
PTO speeds at engine revs.
PTO speeds
540 540E (750) 1000
(A70, A80, A80L) 540 + 540E
1890 1594 (2214) -
( A90, A100, A110) 540 + 1000
1890 - 2074
Powered Front Axle
Differential lock……………………………………… mechanically, controlled by lever
Total reduction…………………………………… 15.75
Front axle / Rear axle ratio...........…………………... 1.343
Differential oil volume..........…………………………. 6,5 lt
Steering reduction oil volume...........……………....... 2 × 0,7 lt
Flansh distance,front axle 4WD……………………… 1580 mm
Steering turning angle,adjustable....................…….. max. Value 55°
Turning angle over pin…………………………………± 13.5°
Camber angle………………………………………...... 1,5°
King – Pin (Axle pin) angle ………………………. … 5°
Caster angle……………………………………………. 5°
Toe-in…………………………………………………. 0-2 mm
Lower link end distance from PTO shaft
(T---measure, mm)
PTO shaft
The length of the lower PTO shaft
links (mm)
6-splines
900
604
