54
8.4.5. Grease door hinges (15)
There are nipples on door hinges.
8.4.6. Change engine oil and engine
oil filter (16)
In extremely dusty conditions or when using over
5% Biodiesel fuel, the oil and filters should be
changed every 250 hours.
If the amount of operating hours is low, the oil and
filters should be changed at least once per year.
8.4.6.1. Draining
Remove the drain plug and allow the oil to run out
into a suitable container. Drain the oil while the
engine is warm (makes draining quicker particularly
in cold weather). Clean the plug and replace it.
8.4.6.2. Changing oil filter
-
Remove the oil filter (1) by unscrewing it
- Wipe off the oil which has run out on the chassis
- Oil the new gasket
- Tighten the new filter by hand (not too hard).
8.4.6.3. Crankcase ventilation
When changing the oil always check that the
ventilation pipe is clean and not blocked.
8.4.6.4. Filling
Fill up with new oil to the prescribed level (upper
mark on dipstick 3) through the filler opening (2).
Oil volume incl. filter
A70 / A70L / A80, A80L…………… ……..8lt.
A90 / A100 / A110……………….. 11lt
Filter capacity ……………………..0.5It
Then start the engine in the normal way. Allow the
engine to idle for a little while and check the oil level
again.
8.4.7. Check free travel of brake
pedals (17)
The free travel should be 69 mm when the pedals
are connected together. Adjust the free travel if
necessary (see under ” Checks and adjustments” ).
8.4.7.1. Adjusting parking brake
The parking brake acts on the foot brake
mechanism mechanically by means of a rod. Adjust
the free travel if necessary. (see under ”Checks and
Adjustments”).
