14
Setup Procedure
Gladiator Conductivity Switch Series
Smart Probe Version
1. Mount the unit in its actual position.
(See mounting procedure - pages 6-7)
• Make sure that external ground wire is connected
between the outside ground screw on the Gladiator
housing and the roof/wall/side of the silo/tank/
vessel/chute. (For non metallic tanks make sure that
external ground wire is connected between the
same outside ground screw on the housing and the
general plant ground potential).
2. Check where the actual level is relative to
the probe
• Make sure that the liquid is not touching the probe
or probes.
3. Turn the power on
• The green LED will either stay on for 2 seconds
then begin flashing or stay on permanently to
indicate operation.
4. Select the required relay contact action
• The Relay can switch ‘ON’ or ‘OFF’ as the product
approaches the probe and switch ‘ON’ or ‘OFF’ in
response to an instrument failure (for details
see page 10).
• Set the relay action selection switch position (FSL or
FSH) depending on your requirements.
5.Cancelinuenceofmounting
• Do not proceed with this step unless the liquid is not
touching the probe or probes.
• Switch the Mounting Calibration switch to ‘CAL’
(ON) position. The Blue LED will blink to indicate
that mounting calibration is now in progress.
• Wait for at least 10 sec. then switch the mounting
calibration switch to ‘OFF’ position.
• The blue LED should turn off after a short time.
• The blue LED will stay on if there was a calibration
error.
• If this is the case please check that the probe is not
touching the product or the mounting, then try the
calibration again.
• If mounting calibration was successful the blue LED
should be off and the Green LED should blink every
2 sec.
• Unit is now able to cancel influence of mounting and
probe history has been cleared.
To Next Page
